Ochiki 50 Amp Cs6364 Generator Connector, 50 and 50 similar items

Ochiki 50 Amp Cs6364 Generator Connector, 50 Amp Generator Plug Female 125/250 Install steps: Step 1: Prepare the cables 1. Remove the power cord end. 2. Strip the outer sheath of the power cord by 2.0 inches from the end, taking care not to cut the insulation layer of the inner cord. 3. Remove all colored conductor cables 0.59 inches Step 2: Assemble the connector 1. Loosen the three fixing screws of the connector and remove the cover of the connector. 2. Connect the exposed copper on each wire to the appropriate terminal and tighten the screws. The green wire is inserted into the green hole marked "G", the white or gray wire is inserted into the hole marked "W", and the main wire (black, red, etc.) is inserted into the hole marked "X" or "Y". 3. Slide the rope into the strain relief device until the edge of the ribbon cable protrudes from the inner edge of the strain relief device. 4. Tighten the strain relief screws. Noted: Please install under the guidance of professionals. Make sure to cut off the power during installation and use female generator connector in a dry place to reduce the risk of electric shock and fire. Service: We'll provide 24-month service, if you have any questions please contact us, we'll reply to you as quickly as possible. Product Features Fitments: Female generator connector fit for generators up to 12,500 watts, CS6364 and 50 amp connector Heavy-duty Power Cord Plug: This 50 amp connector is a heavy-duty power cord plug for generator, can be used in industrial equipment, generators, stage lighting, machine rooms, transfer switches, welding equipment, RV, trailers and etc Easy to Install: It only takes two steps, first step is to prepare the cable, and the second step is to assemble the connector. If you have any questions during the installation, please feel free to contact us Please Noted: Make sure to cut off the power during installation and use female generator connector in a dry place to reduce the risk of electric shock and fire What You Will Get: 1* LL550C 50 Amp generator connector female and 24-month service, if you have any questions please contact us, we'll reply to you as quickly as possible Shipping: Shipping is complimentary within the lower 48 US States. We Do Not Ship to PO/APO Boxes, HI or Alaska We Do Not Ship Outside of the Continental US All items ship within 24-72 hours of Payment For large items that require Freight shipping a valid phone number is required to call and schedule your delivery Terms of Sale and Feedback: Feedback is extremely important to us and If you are satisfied with our transaction, please take a moment to leave Positive Feedback. YOUR Satisfaction is our #1 Priority! If there are any issues, PLEASE contact us BEFORE leaving a neutral or negative rating so that we may resolve any concerns. We PROMISE we can make you happy if you give us a fair chance. Returns / Concerns: All items qualify for returns within 14 - 30 days of receipt. Buyer is responsible for return shipping on any item that is not damaged Please be sure this is an item you want before making your purchase. Customer Satisfaction is our TOP priority! All items are IN STOCK at time of listing. Inventory changes constantly and it is impossible to maintain a perfectly accurate count of all items. Please do not penalize us if we have to issue you a refund! Thank You For Your Business!
